Bustype: Dobbeltdækkerbus

Volvo Bussar AB, Göteborg (S), Irvine (GB)

Type:

B55-50 "Ailsa"

Årgang 1973 - 1985

Type:

B55-55 "Ailsa"

Årgang 1973 - 1985

Type:

B55-60 "Ailsa"

Årgang 1973 - 1985

Volvo B55-55 - Alexander, Cobham Bus Museum, London Transport V3
foto: April 2008, "Arriva 436" ©



The Volvo Ailsa B55 was a front-engined double-decker bus chassis built in Scotland by Ailsa, Volvo's British commercial vehicle agency. It was in production from 1973 to 1985, and was a relatively successful alternative to the ubiquitous rear-engined Bristol VR, Leyland Atlantean and Daimler/Leyland Fleetline of the period.

The vehicle first appeared at the 1973 Scottish Motor Show, and was well received.

Versions: The chassis was designed with a front mounted engine that still allowed a front entrance position suitable for one-person operation. In this sense there was a common goal with the earlier, unsuccessful, Guy Wulfrunian. The engine was the Volvo TD70, a compact turbocharged unit of 6.7-litres. The rest of the design was relatively simple, with beam axles and leaf springs. A Self-Changing Gears semi-automatic gearbox was used.

A prototype lowheight Ailsa, designated B55-20 (instead of the standard B55-10), was delivered to Derby Borough Transport in 1977. It remained a one-off and is now owned by WJC Coaches in Scotland.

In 1977 an improved MkII version appeared, with two transmission options offered - a Self-Changing Gears pneumocyclic unit and a Voith D851 with retarder. It was followed in 1980 by a MkIII version, for which the Ailsa name was dropped. This continued to use the Volvo TD70H turbocharged engine, and utilized a Volvo truck rear axle in place of the previous troublesome axle. Air suspension was also an available option.

In 1981, a 3-axle version of Ailsa B55 was developed to meet the demand of 3-axle buses in Hong Kong. (kilde: Wikipedia)



Volvo Logo





Tekniske Data:      Volvo B55 "Ailsa" - produktion: 1.021 stk.

Årgang:

 1973 - 1985

Chassisnr.:

 -

Motor:

 Volvo Diesel type TD70E/201 (6-Cyl. frontmotor)

Ydelse:

 201 HK (v/ 2.400 O/min.) ?? Nm

Gear:

 Halvautomatisk SCG GB350 eller
 fuldautomatisk gearkasse.

Topfart:

 80 km/t.*

Passagertal:

 ?? siddende og ?? stående passagerer.*

Længde:

 9.781 ** mm

Bredde:

 2.355 * mm

Højde:

 - * mm (afhængig af karrosserimodel)

Akselafstand:

 4.953 mm (B55-50**), 5.500 mm (B55-55)
 6.000 mm (B55-60).

Vendediameter:

 21,8 ** m

Totalvægt:

 16.256 ** kg

Bremser:

 - 2-kreds trykluft -

Dækstørrelse:

 11.00-22.5

  * = afhængig af specifikationer.
** = B55-50.
